Otu (okpukpu abụọ) Akara akara D 40-70mm

Otu (okpukpu abụọ) Akara akara D 40-70mm onyonyo egosipụtara
  • Otu (okpukpu abụọ) Akara akara D 40-70mmOtu (okpukpu abụọ) Akara akara D 40-70mm
  • Otu (okpukpu abụọ) Akara akara D 40-70mmOtu (okpukpu abụọ) Akara akara D 40-70mm
  • Otu (okpukpu abụọ) Akara akara D 40-70mmOtu (okpukpu abụọ) Akara akara D 40-70mm
  • Otu (okpukpu abụọ) Akara akara D 40-70mmOtu (okpukpu abụọ) Akara akara D 40-70mm

Nkọwa dị mkpirikpi:


Nnọọ na-ebu ibu, nabata ileta ụlọ ọrụ anyị


  • Ọnụ ego FOB:
  • Ọnụ ọgụgụ nke Min.Iberibe 500-1000
  • Ikike inye:100000 Iberibe / kwa ọnwa
  • Port:Ningbo/Shanghai
  • Usoro ịkwụ ụgwọ:T/T, L/C
    • Budata dị ka PDF

    Nkọwa ngwaahịa

    Mkpado ngwaahịa

    Akụkụ oke (mm) Ọkwa ibu (kN) Mmachi ọsọ (r/min) Nọmba Akụkụ mgbago (mm) Ibu
    (ntụaka)
    (kg)
    d D B r1,2
    min    		 Cr Cor Griiz
    -RZ-2RZ    		 Griiz
    -2RS1    		 Mmanụ -RZ -2RZ -2RS1 da
    min    		 Da
    max    		 ra
    max
    ?40 80 23 1.1 27,600 17.400 8500 5600 10000 62208-RZ 62208-2RZ 62208-2RS1 46.5 73.5 1.0 0,4720
    40 90 33 1.5 40,800 24,000 7500 5000 9000 62308-RZ 62308-2RZ 62308-2RS1 48.0 82.0 1.5 0,8900
    45 85 23 1.1 31.200 20,400 7500 5000 9000 62209-RZ 62209-2RZ 62209-2RS1 51.5 78.5 1.0 0,4900
    45 100 36 1.5 48,900 29.300 6700 4500 8000 62309-RZ 62309-2RZ 62309-2RS1 53.0 92.0 1.5 1.1500
    50 90 23 1.1 35.100 23.200 7000 4800 8500 62210-RZ 62210-2RZ 62210-2RS1 56.5 83.5 1.0 0,5260
    50 110 40 2.0 57,600 35.300 6300 4300 7500 62310-RZ 62310-2RZ 62310-2RS1 59.0 101.0 2.0 1.5500
    55 100 25 1.5 43,400 29.200 6300 4300 7500 62211-RZ 62211-2RZ 62211-2RS1 63.0 92.0 1.5 0,7000
    55 120 43 2.0 71,600 44,800 5600 3800 6700 62311-RZ 62311-2RZ 62311-2RS1 64.0 111.0 2.0 1.1950
    60 110 28 1.5 47.800 32.900 6000 4000 7000 62212-RZ 62212-2RZ 62212-2RS1 68.0 102.0 1.5 0,9980
    60 130 46 2.1 81.900 51.800 5000 3400 6000 62312-RZ 62312-2RZ 62312-2RS1 71.0 119.0 2.0 2.5000
    65 120 31 1.5 50,700 37.100 5300 3600 6300 62213-RZ 62213-2RZ 62213-2RS1 73.0 129.0 1.5 1,3700
    65 140 48 2.1 92,800 59,700 4800 3200 5600 62313-RZ 62313-2RZ 62313-2RS1 76.0 129.0 2.0 3,0000
    70 125 31 1.5 55,800 41.100 5000 3400 6000 62214-RZ 62214-2RZ 62214-2RS1 78.0 117.0 1.5 1.4100
    70 150 51 2.1 104,000 68,000 4500 3000 5300 62314-RZ 62314-2RZ 62314-2RS1 81.0 139.0 2.0 3.5500
